Product Info
Description
This package provides a ready-to-use base PLC project developed in Siemens TIA Portal V15, designed to accelerate the integration and testing of industrial automation projects inside the Nirtec Machine Simulator environment.
The product includes a structured base program, a NetToPLCSim configuration file, and the required drivers to link simulator variables with the Siemens PLC simulator.
It allows users to quickly establish communication between the virtual machine environment and the PLC simulation, making it ideal for automation engineers, PLC programmers, and students working with industrial control systems.
The base project can be used as a starting template for developing and testing PLC logic while interacting with simulated machines.
Includes
This package includes the following files and resources:
• Siemens TIA Portal V15 base PLC project
• Preconfigured NetToPLCSim simulation file (.simu)
• Communication drivers for integration with Machine Simulator
• Basic PLC variable mapping structure
• Example tags prepared for simulator interaction
The project is intended to provide a ready-to-use starting point for PLC simulation and virtual machine testing.
Installing Instruction
1. Open the project using Siemens TIA Portal V15.
2. Start the Siemens PLC simulator (PLCSIM).
3. Launch NetToPLCSim and load the provided .simu configuration file.
4. Connect NetToPLCSim to the running PLCSIM instance.
5. Open Machine Simulator and load the corresponding machine model.
6. Configure the communication drivers if required and link the simulator variables to the PLC tags.
After completing these steps, the PLC program will be able to interact with the Machine Simulator environment.
Dependences
The following software is required to use this package:
• Siemens TIA Portal V15
• Siemens PLCSIM
• NetToPLCSim
• Nirtec Machine Simulator 4
All software must be properly installed and configured before using this project.
Siemens TIA Portal Communication Configuration Template
Base PLC program for Siemens TIA Portal V15 including NetToPLCSim configuration and ready-to-use drivers for integration with Nirtec Machine Simulator.
0,00 €
MS Minimun Required Version: v4.4
